OC1M — Output Compare 1 Mask
$100C
Bit 7
OC1M7
0
6
OC1M6
0
5
OC1M5
0
4
OC1M4
0
3
OC1M3
0
2
—
0
1
—
0
Bit 0
—
RESET:
0
OC1M[7:3] — Output Compare Masks
0 = OC1 is disabled.
1 = OC1 is enabled to control the corresponding pin of port A
Bits [2:0] — Not implemented
Always read zero
9.3.4 Output Compare Data Register
Use this register with OC1 to specify the data that is to be stored on the affected pin
of port A after a successful OC1 compare. When a successful OC1 compare occurs,
a data bit in OC1D is stored in the corresponding bit of port A for each bit that is set in
OC1M.
OC1D — Output Compare 1 Data
$100D
Bit 7
OC1D7
0
6
OC1D6
0
5
OC1D5
0
4
OC1D4
0
3
OC1D3
0
2
—
0
1
—
0
Bit 0
—
RESET:
0
If OC1Mx is set, data in OC1Dx is output to port A bit x on successful OC1 compares.
Bits [2:0] — Not implemented
Always read zero
9.3.5 Timer Counter Register
The 16-bit read-only TCNT register contains the prescaled value of the 16-bit timer. A
full counter read addresses the most significant byte (MSB) first. A read of this address
causes the least significant byte (LSB) to be latched into a buffer for the next CPU cy-
cle so that a double-byte read returns the full 16-bit state of the counter at the time of
the MSB read cycle.
TCNT — Timer Counter
$100E, $100F
$100E
$100F
Bit 15
Bit 7
14
6
13
5
12
4
11
3
10
2
9
1
Bit 8
Bit 0
TCNT (High)
TCNT (Low)
TCNT resets to $0000. In normal modes, TCNT is a read-only register.
