Enhanced Serial Audio Interface Timing
Table 22. Enhanced Serial Audio Interface Timing (Continued)
Characteristics1, 2, 3 Expression3 Max Condition4 Unit
Symbol Min
No.
Notes:
1. VCORE_VDD = 1.25 0.05 V; TJ = –40°C to 115°C for 150 MHz; TJ = 0°C to 100°C for 181 MHz; CL = 50 pF
2. i ck = internal clock
x ck = external clock
i ck a = internal clock, asynchronous mode
(asynchronous implies that SCKT and SCKR are two different clocks)
i ck s = internal clock, synchronous mode
(synchronous implies that SCKT and SCKR are the same clock)
3. bl = bit length
wl = word length
wr = word length relative
4. SCKT(SCKT pin) = transmit clock
SCKR(SCKR pin) = receive clock
FST(FST pin) = transmit frame sync
FSR(FSR pin) = receive frame sync
HCKT(HCKT pin) = transmit high frequency clock
HCKR(HCKR pin) = receive high frequency clock
5. For the internal clock, the external clock cycle is defined by Icyc and the ESAI control register.
6. The word-relative frame sync signal waveform relative to the clock operates in the same manner as the bit-length frame sync signal
waveform, but spreads from one serial clock before first bit clock (same as bit length frame sync signal), until the one before last bit
clock of the first word in frame.
7. Periodically sampled and not 100% tested
8. ESAI_1 specs match those of ESAI_0
