Freescale Semiconductor, Inc.
memory access. Off-chip address comparators will not detect breakpoints on internal
accesses unless show cycles are enabled. Breakpoints on prefetched instructions, which
are flushed from the pipeline before execution, are not acknowledged, but operand
breakpoints are always acknowledged. Acknowledged breakpoints can initiate either
exception processing or BDM. See 5.5.2.6 Hardware Breakpoints for more information.
5.6.2 Background Debug Mode
BDM is an alternate CPU32 operating mode. During BDM, normal instruction execution is
suspended, and special microcode performs debugging functions under external control.
Figure 5-20 is a BDM block diagram.
BDM can be initiated in several ways—by externally generated breakpoints, by internal
peripheral breakpoints, by the background instruction (BGND), or by catastrophic
exception conditions. While in BDM, the CPU32 ceases to fetch instructions via the
parallel bus and communicates with the development system via a dedicated, high-speed,
SPI-type serial command interface.
SERIAL
INTERFACE
IPIPE/DSO
MICROCODE
SEQUENCER
IFETCH/DSI
IRC
IRB
IR
BKPT/DSCLK
BERR
BKPT
BERR
BKPT
BERR
BKPT
BUS
CONTROL
DATA BUS
BERR
.
F... REEZE
.
EXECUTION
UNIT
ADDRESS BUS
Figure 5-20. BDM Block Diagram
5.6.2.1 ENABLING BDM. Accidentally entering BDM in a nondevelopment environment
could lock up the CPU32 since the serial command interface would probably not be
available. For this reason, BDM is enabled during reset via the BKPT signal.
MOTOROLA
MC68340 USER’S MANUAL
5- 65
