4.4.3 SIM40 Example Configuration Code
The following code is an example configuration sequence for the SIM40 module.
***************************************************************************
* MC68340 basic SIM40 register initialization example code:
* This code is used to initialize the MC68340's internal SIM40 registers,
* providing basic functions for operation.
* It includes chip select programming for external devices.
* This code would be programmed beginning at offset $0 into ROM which is
* relocated to address $60000 by the initialization code.
* The SSP_VEC and RST_VEC vectors used to initialize the system stack
* pointer and initial PC, respectively, are located at offset $0 after
* reset.
***************************************************************************
* equates
***************************************************************************
SSP_INIT
MBAR
EQU $10000
Stack pointer initial value - top of RAM
EQU $0003FF00 Address of Module Base Address Reg.
MODBASE EQU $FFFFF000 Default Module Base address value
****************************************
* SIM40 register offsets from MBAR base address
MCR
EQU $00
EQU $04
EQU $21
EQU $40
EQU $44
EQU $48
EQU $4c
EQU $50
EQU $54
EQU $58
EQU $5c
SYNCR
SYPCR
CSAM0
CSBAR0
CSAM1
CSBAR1
CSAM2
CSBAR2
CSAM3
CSBAR3
***************************************************************************
* Reset vectors
* These two vectors should be located at addresses $0 and $4 after a processor
* hardware reset.
***************************************************************************
ORG $60000
SSP_VEC DC.L SSP_INIT
RST_VEC DC.L INIT340
Supervisor stack pointer - initial value
Reset vector pointing to initialization code
