Table 4-36 Power Supervisor Registers Address Map
(LVI_BASE = $00 F360)
Register Acronym
Address Offset
Register Description
LVI_CONTROL
LVI_STATUS
$0
$1
Control Register
Status Register
Table 4-37 Flash Module Registers Address Map
(FM_BASE = $00 F400)
Register Acronym
Address Offset
Register Description
Clock Divider Register
FMCLKD
FMMCR
$0
$1
Module Control Register
Reserved
FMSECH
FMSECL
$3
$4
Security High Half Register
Security Low Half Register
Reserved
Reserved
FMPROT
$10
$11
Protection Register (Banked)
Protection Boot Register (Banked)
Reserved
FMPROTB
FMUSTAT
FMCMD
$13
$14
User Status Register (Banked)
Command Register (Banked)
Reserved
Reserved
FMOPT 0
$1A
16-Bit Information Option Register 0
Hot temperature ADC reading of Temperature Sensor;
value set during factory test
FMOPT 1
FMOPT 2
$1B
$1C
16-Bit Information Option Register 1
Not used
16-Bit Information Option Register 2
Room temperature ADC reading of Temperature Sensor;
value set during factory test
56F8345 Technical Data, Rev. 17
68
Freescale Semiconductor
Preliminary
