Peripheral Memory-Mapped Registers

Table 4-31 I C Registers Address Map

(I2C_BASE = $00 F280)

Address Offset

I2C_CTRL

I2C_TAR

I2C_SAR

I2C_DATA

Control Register

Target Address Register

Slave Address Register

RX/TX Data Buffer and Command Register

Standard Speed Clock SCL High Count Register

Standard Speed Clock SCL Low Count Register

Fast Speed Clock SCL High Count Register

Fast Speed Clock SCL Low Count Register

Interrupt Status Register

I2C_SSHCNT

I2C_SSLCNT

I2C_FSHCNT

I2C_FSLCNT

I2C_ISTAT

$10

$16

$18

$1A

$1C

$1E

$20

$22

$24

$26

$28

$2A

$2C

$2E

$30

$32

$34

$36

$38

$3A

$3C

$40

I2C_IMASK

Interrupt Mask Register

I2C_RISTAT

Raw Interrupt Status Register

I2C_RXFT

Receive FIFO Threshold Register

Transmit FIFO Threshold Register

Clear Combined and Individual Interrupts Register

Clear RX_UNDER Interrupt Register

Clear RX_OVER Interrupt Register

Clear TX_OVER Interrupt Register

Clear RD_REQ Interrupt Register

Clear TX_ABRT Interrupt Register

Clear RX_DONE Interrupt Register

Clear Activity Interrupt Register

Clear STOP_DET Interrupt Register

Clear START_DET Interrupt Register

Clear GEN_CALL Interrupt Register

Enable Register

I2C_TXFT

I2C_CLRINT

I2C_CLRRXUND

I2C_CLRRXOVR

I2C_CLRTXOVR

I2C_CLRRDREQ

I2C_CLRTXABRT

I2C_CLRRXDONE

I2C_CLRACT

I2C_CLRSTPDET

I2C_CLRSTDET

I2C_CLRGC

I2C_ENBL

I2C_STAT

Status Register

I2C_TXFLR

Transmit FIFO Level Register

I2C_RXFLR

Receive FIFO Level Register

I2C_TXABRTSRC

Transmit Abort Status Register

56F8037 Data Sheet, Rev. 3

Freescale Semiconductor

Preliminary
