Reset Values
Table 8-2 GPIO External Signals Map (Continued)
LQFP
Package Pin
Notes
GPIO Function
Peripheral Function
ANB1
GPIOC5
GPIOC6
9
Defaults to C5
ANB2 / VREFHB
10
SIM register SIM_GPS is used to
select between ANB2 and VREFHB
.
Defaults to C6
GPIOC7
ANB3 / VREFLB
11
SIM register SIM_GPS is used to
select between ANB3 and VREFLB
.
Defaults to C7
GPIOC8
GPIOC12
GPIOD0
GPIOD1
GPIOD2
GPIOD3
GPIOD4
GPIOD5
ANA4
ANB4
TDI
18
7
Defaults to C8
Defaults to C12
Defaults to TDI
Defaults to TDO
Defaults to TCK
Defaults to TMS
Defaults to D4
45
48
21
47
41
40
TDO
TCK
TMS
EXTAL
XTAL / CLKIN
SIM register SIM_GPSCD is used to
select between XTAL and CLKIN.
Defaults to D5
8.3 Reset Values
