Introduction
VDD_IO
VSS_IO
VDDA
Power
Ground
Power
1
2
1
1
VSSA
Ground
56F8014
GPIOB0 (SCLK, SCL)
GPIOB1 (SS, SDA)
Other
Supply
Ports
1
1
SPI Port or
VCAP
I2C Port or
Timer Port
or GPIO
1
GPIOB2 (MISO, T2)
GPIOB3 (MOSI, T3)
1
1
GPIOB6 (RXD, SDA, CLKIN)
GPIOB7 (TXD, SCL)
SCI Port or
I2C Port or
GPIO
GPIOA0 - 2 (PWM0 - 2)
1
1
3
PWM Port or
Timer Port or
GPIO
GPIOA4 (PWM4, FAULT1, T2)
GPIOA5 (PWM5, FAULT2, T3)
1
1
RESET
RESET (GPIOA7)
1
ANA0 - 1 (GPIOC0 - 1)
2
ANA2 (VREFH, GPIOC2)
ANA3 (GPIOC3)
GPIOB4 (T0, CLKO)
GPIOB5 (T1, FAULT3)
1
1
Timer Port
or GPIO
1
1
ADC Port or
GPIO
ANB0 - 1 (GPIOC4 - 5)
ANB2 (VREFL, GPIOC6)
ANB3 (GPIOC7)
2
1
1
TCK (GPIOD2)
1
TMS (GPIOD3)
TDI (GPIOD0)
TDO (GPIOD1)
JTAG/
EOnCE Port
or GPIO
1
1
1
Figure 2-1 56F8014 Signals Identified by Functional Group (32-Pin LQFP)
56F8014 Technical Data, Rev. 9
Freescale Semiconductor
Preliminary
17
