Document No.: FT_000288
FT232H SINGLE CHANNEL HI-SPEED USB TO MULTIPURPOSE UART/FIFO IC
Datasheet Version 1.8
Clearance No.: FTDI #199
4.4 FT245 Synchronous FIFO Interface Mode Description
When FT232H is configured in an FT245 Synchronous FIFO interface mode the IO timing of the signals
used are shown in Figure 4.4 which shows details for read and write accesses. The timings are shown in
Figure 4.4.Note that only a read or a write cycle can be performed at any one time. Data is read or
written on the rising edge of the CLKOUT clock.
Figure 4.4 FT245 Synchronous FIFO Interface Signal Waveforms
