Document No.: FT_000288
FT232H SINGLE CHANNEL HI-SPEED USB TO MULTIPURPOSE UART/FIFO IC
Datasheet Version 1.8
Clearance No.: FTDI #199
4.3 FT232 UART Interface Mode Description
The FT232H can be configured as a UART with external line drivers, similar to operation with the FTDI
FT232R devices. The following examples illustrate how to configure the FT232H with an RS232, RS422 or
RS485 interface.
4.3.1 RS232 Configuration
Figure 4.1 illustrates how the FT232H can be configured with an RS232 UART interface.
Figure 4.1 RS232 Configuration
Copyright © 2012 Future Technology Devices International Limited
24
