ZSPM1025A
True Digital PWM Controller (Single-Phase, Single-Rail)
4.7.16. READ_IOUT
READ_IOUT (read only)
Bits
Name
Description
Output current in A (linear data format).
[15:0]
IOUT
4.7.17. READ_TEMPERATURE1
READ_TEMPERATURE1 (read only)
Description
Bits
Name
[15:0]
TEMP1
External temperature in °C (linear data format).
4.7.18. READ_TEMPERATURE2
READ_TEMPERATURE2 (read only)
Description
Bits
Name
[15:0]
TEMP2
Internal temperature in °C (linear data format).
© 2013 Zentrum Mikroelektronik Dresden AG — Rev. 1.00
All rights reserved. The material contained herein may not be reproduced, adapted, merged, translated, stored, or used without the
prior written consent of the copyright owner. The information furnished in this publication is subject to changes without notice.
Data Sheet
October 24, 2013
32 of 46
