ZSPM1025A
True Digital PWM Controller (Single-Phase, Single-Rail)
4.7.9.
STATUS_IOUT
STATUS_IOUT (read only)
Bits
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
Name
Description
Not supported.
Not supported.
Not supported.
Not supported.
Not supported.
IOUT_OC_WARN
An over-current warning has occurred.
Not supported.
.
IOUT_OC_FLT
An over-current fault has occurred.
4.7.10. STATUS_INPUT
STATUS_INPUT (read only)
Bits
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
Name
Description
Not supported.
Not supported.
Not supported.
Not supported.
VIN_UV_FLT
An input voltage under-voltage fault has occurred.
An input voltage under-voltage warning has occurred.
An input voltage over-voltage warning has occurred.
An input voltage over-voltage fault has occurred.
VIN_UV_WARN
VIN_OV_WARN
VIN_OV_FLT
4.7.11. STATUS_TEMPERATURE
STATUS_TEMPERATURE (read only)
Description
Bits
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
Name
Not supported.
Not supported.
Not supported.
Not supported.
Not supported.
Not supported.
TEMP_OV_WARN
TEMP_OV_FLT
An (external) over-temperature warning has occurred.
An (external) over-temperature fault has occurred.
© 2013 Zentrum Mikroelektronik Dresden AG — Rev. 1.00
All rights reserved. The material contained herein may not be reproduced, adapted, merged, translated, stored, or used without the
prior written consent of the copyright owner. The information furnished in this publication is subject to changes without notice.
Data Sheet
October 24, 2013
30 of 46
