ZSPM1025A
True Digital PWM Controller (Single-Phase, Single-Rail)
4.7.4.
VOUT_MODE
The VOUT_MODE command is used to retrieve information about the data format for all output voltage related
commands. Note that this is a read-only value.
VOUT_MODE (read only)
Bits
[4:0]
[7:5]
Name
PARAMETER
MODE
Description
2’s complement of the exponent
000: Linear data format
4.7.5.
VOUT_COMMAND
The VOUT_COMMAND is used to set the output voltage during run-time.
Note that the maximum output voltage is 3.6V.
VOUT_COMMAND (read/write)
Bits
Name
MANTISSA
Description
Unsigned mantissa of output voltage in V.
[15:0]
Exponent can be retrieved via VOUT_MODE command.
4.7.6.
STATUS_BYTE
The STATUS_BYTE command returns a summary of the most critical faults in one byte.
STATUS_BYTE (read only)
Bits
[0]
[1]
[2]
[3]
[4]
[5]
Name
NONE OF THE ABOVE
CML
Description
A fault not listed in bits [7:1] has occurred.
A communication fault as occurred.
TEMPERATURE
VIN_UV
A temperature fault or warning has occurred.
An input under-voltage fault has occurred.
An output over-current fault has occurred.
An output over-voltage fault has occurred.
IOUT_OC
VOUT_OV
This bit is asserted if the unit is not providing power to the output,
regardless of the reason, including simply not being enabled.
[6]
[7]
OFF
BUSY
Not supported.
© 2013 Zentrum Mikroelektronik Dresden AG — Rev. 1.00
All rights reserved. The material contained herein may not be reproduced, adapted, merged, translated, stored, or used without the
prior written consent of the copyright owner. The information furnished in this publication is subject to changes without notice.
Data Sheet
October 24, 2013
28 of 46
