DA14580
FINAL
Bluetooth Low Energy 4.2 SoC
Table 29: WKUP_COMPARE_REG (0x50000102)
Bit
Mode Symbol
Description
Reset
15:8
7:0
-
-
Reserved
0x0
0x0
R/W
COMPARE
The number of events that have to be counted before the
wakeup interrupt will be given
Table 30: WKUP_RESET_IRQ_REG (0x50000104)
Bit
Mode Symbol
WKUP_IRQ_RST
Description
Reset
15:0
W
writing any value to this register will reset the interrupt. read- 0x0
ing always returns 0.
Table 31: WKUP_COUNTER_REG (0x50000106)
Bit
Mode Symbol
Description
Reset
0x0
15:8
7:0
-
-
Reserved
R
EVENT_VALUE
This value represents the number of events that have been
counted so far. It will be reset by resetting the interrupt.
0x0
Table 32: WKUP_RESET_CNTR_REG (0x50000108)
Bit
Mode Symbol
WKUP_CNTR_RST
Description
Reset
15:0
W
writing any value to this register will reset the event counter
0x0
Table 33: WKUP_SELECT_P0_REG (0x5000010A)
Bit
Mode Symbol
R/W WKUP_SELECT_P0
Description
Reset
7:0
0: input P0x is not enabled for wakeup event counter
1: input P0x is enabled for wakeup event counter
0x0
Table 34: WKUP_SELECT_P1_REG (0x5000010C)
Bit
Mode Symbol
R/W WKUP_SELECT_P1
Description
Reset
5:0
0: input P1x is not enabled for wakeup event counter
1: input P1x is enabled for wakeup event counter
0x0
Table 35: WKUP_SELECT_P2_REG (0x5000010E)
Bit
Mode Symbol
R/W WKUP_SELECT_P2
Description
Reset
9:0
0: input P2x is not enabled for wakeup event counter
1: input P2x is enabled for wakeup event counter
0x0
Table 36: WKUP_SELECT_P3_REG (0x50000110)
Bit
Mode Symbol
R/W WKUP_SELECT_P3
Description
Reset
7:0
0: input P3x is not enabled for wakeup event counter
1: input P3x is enabled for wakeup event counter
0x0
Datasheet
Revision 3.4
09-Nov-2016
CFR0011-120-01
35 of 155
