BNCꢀSeries
Unit：mm
○Straight Bulkhead Cable Jack
Finish
Center
Conductor Conductor
+0.1
Part Number
Note
0
φ9.6
Outer
ꢀHex Dia.12.7
Independent
Waterproof
BNC-RBP1-CF
Ag
Ag
with Frange O-ring
Independent
2.5
BNC-RBP1-Ni-CF
Ni
Ag
Waterproof
+0.1
0
with Frange O-ring
15.2
8.5
32.6
Panel Mounting Dimensions
Panel Thickness：2.6〜6.4
+0.1
Finish
Center
Conductor Conductor
ꢀHex Dia.12.7
0
φ9.6
Part Number
Note
Outer
BNC-RB-CF
BNC-RB-Ni-CF
Ag
Ag
with Frange O-ring
with Frange O-ring
Ni
Ag
2.3
17.4
33
+0.1
0
8.5
Panel Mounting Dimensions
Panel Thickness：2.2〜7.0
○Dust Cap
Marking
ꢀJCW-159/U-CF/DDK
(17.8)
(20.5)
Part Number
BNC-CS-CF
Finish
Ag
Part Number
BNC-JC-CF
BNC-JC-Ni-CF
Finish
Short Cap
Short Cap
Ag
Ni
BNC-CS-Ni-CF
Ni
（φ3.5）
Part Number
BNC-RC-3
BNC-RC-3-D1
Finish
Ni
BNC style mating side
Marking：DDK
Ag
60±5
(75)
◎ Please acknowledge that the specification etc. of this catalog might change by the improvement etc. without notice.
ꢀMoreover, the characteristic and the specification of the published product are the reference values.
ꢀPlease confirm the content with the latest delivery specifications when you use the product.
