BNCꢀSeries
Unit：mm
○Receptacle Jack
Finish
Part Number
Note
+0.1
Outer
Center
0
5-φ1.2
Conductor Conductor
Board lock is
Ag plating
BNC-R-PC-4-Ag-CF
BNC-R-PC-4-D1-CF
Ni
Ni
Ag
Au
Board lock is
Ag plating.
2.3
13.3
2.5
±0.05
5.08
+0.1
0
10.16
PCB Mounting Dimensions
Finish
Center
Conductor Conductor
10.16
Part Number
Note
+0.1
Outer
0
5-φ1.2
Board lock is
Ag plating
BNC-LR-PC-4-Ag-CF
Ni
Ag
Board lock is
Ag plating
BNC-LR-PC-4-NiCAu-CF
Ni
Au
2.5
19.1
±0.05
5.08
+0.1
0
10.16
PCB Mounting Dimensions
Finish
4-φ3.0
+0.1
0
4-φ3.0
Part Number
Outer
Center
Conductor Conductor
BNC-PR-CF
BNC-PR-Ni-CF
Ag
Ni
Ag
Ag
+0.1
0
φ9.0
2.3
（17.7）
（28.2）
12.7
□17.5
±0.05
12.7
Panel Mounting Dimensions
◎ Please acknowledge that the specification etc. of this catalog might change by the improvement etc. without notice.
ꢀMoreover, the characteristic and the specification of the published product are the reference values.
ꢀPlease confirm the content with the latest delivery specifications when you use the product.
