BNCꢀSeries
Unit：mm
○Assembly Instruction（3）
Parts Configulration
（for 2.5D-2V）
(for 1.5D-2V / RG-179B/U)
Ferule
Contact Assembly
Plug Body
①
Cut the cable as fig.1.
①
20mm
● Please be careful to not damage the outer conductor.
Insert the ferule.
②
②
● In case of 2.5D-2V cable, insert the ferule into the cable
and push the ferule between sheath and outer conductor
until the head of ferule is reached to the sheath by
inserting tool(E3001-160) and pick the outer conductor.
● In case of 1.5D-2V or RG-179B/U cable , insert the
ferule until the ferule reached at the sheath and pick the
outer conductor.
Inserting Tool
Ferule
2.5D-2V
Ferule
1.5D-2V,RG-179B/U
Folding down the outer conductor to the ferule and
cut the couter conductor along the ferule as fig.3.
Cut the insulator and center conductor and pre-solder
the center conductor.
③
A
17mm
10mm
③
④
Applicable Cable
2.5D-2V
1.5-2V, RG-179B/U
A
4mm
5mm
Soldering
Insert the contact assembly into the above cable
assembly. Solder up the contact with center conductor
and crimp the root of the contact assembly.
④
1mm
crimping
Insert the body into the above cable assembly and
screw up the body by the wrench tightly.
⑤
⑤
Recommended Tightening Torque
: 196 N･cm(20kgf･cm)
◎ Please acknowledge that the specification etc. of this catalog might change by the improvement etc. without notice.
ꢀMoreover, the characteristic and the specification of the published product are the reference values.
ꢀPlease confirm the content with the latest delivery specifications when you use the product.
http://www.ddknet.co.jp
11
