DS2154
TSaCR: TRANSMIT Sa BIT CONTROL REGISTER (Address=1C Hex)
(MSB)
(LSB)
SiAF
SiNAF
RA
Sa4
Sa5
Sa6
Sa7
Sa8
SYMBOL POSITION NAME AND DESCRIPTION
SiAF
SiNAF
RA
TSaCR.7
TSaCR.6
TSaCR.5
TSaCR.4
TSaCR.3
TSaCR.2
TSaCR.1
TSaCR.0
International Bit in Align Frame Insertion Control Bit.
0=do not insert data from the TSiAF register into the transmit data
stream
1=insert data from the TSiAF register into the transmit data stream
International Bit in Non-Align Frame Insertion Control Bit.
0=do not insert data from the TSiNAF register into the transmit data
stream
1=insert data from the TSiNAF register into the transmit data stream
Remote Alarm Insertion Control Bit.
0=do not insert data from the TRA register into the transmit data
stream
1=insert data from the TRA register into the transmit data stream
Sa4
Additional Bit 4 Insertion Control Bit.
0=do not insert data from the TSa4 register into the transmit data
stream
1=insert data from the TSa4 register into the transmit data stream
Sa5
Additional Bit 5 Insertion Control Bit.
0=do not insert data from the TSa5 register into the transmit data
stream
1=insert data from the TSa5 register into the transmit data stream
Sa6
Additional Bit 6 Insertion Control Bit.
0=do not insert data from the TSa6 register into the transmit data
stream
1=insert data from the TSa6 register into the transmit data stream
Sa7
Additional Bit 7 Insertion Control Bit.
0=do not insert data from the TSa7 register into the transmit data
stream
1=insert data from the TSa7 register into the transmit data stream
Sa8
Additional Bit 8 Insertion Control Bit.
0=do not insert data from the TSa8 register into the transmit data
stream
1=insert data from the TSa8 register into the transmit data stream
61 of 87
