DS2154
RAF: RECEIVE ALIGN FRAME REGISTER (Address=2F Hex)
(MSB)
(LSB)
Si
0
0
1
1
0
1
1
SYMBOL
POSITION NAME AND DESCRIPTION
Si
0
0
1
1
0
1
1
RAF.7
RAF.6
RAF.5
RAF.4
RAF.3
RAF.2
RAF.1
RAF.0
International Bit.
Frame Alignment Signal Bit.
Frame Alignment Signal Bit.
Frame Alignment Signal Bit.
Frame Alignment Signal Bit.
Frame Alignment Signal Bit.
Frame Alignment Signal Bit.
Frame Alignment Signal Bit.
RNAF: RECEIVE NON-ALIGN FRAME REGISTER (Address=1F Hex)
(MSB)
(LSB)
Si
1
A
Sa4
Sa5
Sa6
Sa7
Sa8
SYMBOL
POSITION NAME AND DESCRIPTION
Si
1
RNAF.7
RNAF.6
RNAF.5
RNAF.4
RNAF.3
RNAF.2
RNAF.1
RNAF.0
International Bit.
Frame Non-Alignment Signal Bit.
Remote Alarm.
A
Sa4
Sa5
Sa6
Sa7
Sa8
Additional Bit 4.
Additional Bit 5.
Additional Bit 6.
Additional Bit 7.
Additional Bit 8.
58 of 87
