4. Packaging Information
This chapter illustrates the packaging specifications for the CY8C21x34 PSoC device, along with the thermal impedances for each
package.
Important Note Emulation tools may require a larger area on the target PCB than the chip’s footprint. For a detailed description of
the emulation tools’ dimensions, refer to the document titled PSoC Emulator Pod Dimensions at
http://www.cypress.com/design/MR10161.
4.1
Packaging Dimensions
51-85068 *B
Figure 4-1. 16-Lead (150-Mil) SOIC
January 12, 2007
Document No. 38-12025 Rev. *K
