PINSA
Port A Pins
7F99
b7
b6
b5
b4
b3
b2
b1
b0
PINA7
PINA6
PINA5
PINA4
PINA3
PINA2
PINA1
PINA0
R
x
R
x
R
x
R
x
R
x
R
x
R
x
R
x
PINSB
Port B Pins
7F9A
b7
b6
b5
b4
b3
b2
b1
b0
PINB7
PINB6
PINB5
PINB4
PINB3
PINB2
PINB1
PINB0
R
x
R
x
R
x
R
x
R
x
R
x
R
x
R
x
OUTC
Port C Pins
7F98
b7
b6
b5
b4
b3
b2
b1
b0
PINC7
PINC6
PINC5
PINC4
PINC3
PINC2
PINC1
PINC0
R
x
R
x
R
x
R
x
R
x
R
x
R
x
R
x
Figure 12-8. PINSn Registers
The PINSn registers contain the current value of the port pins, whether they are selected as
IO ports or alternate functions.
Page 12-12
Chapter 12. EZ-USB Registers
EZ-USB TRM v1.9
