CX82100 Home Network Processor Data Sheet
12.5.3
Timer 3 Counter Register (TM_Cnt3: 0x00350028)
Bit(s)
15:0
Type
RO
Default
16’b0
Name
TM_Cnt3
Description
Timer 3 Current Counter Value.
Timer 3 increments every 1 µs, from 0 to the Timer 3 limit value, then
resets to 0 and counts again. TM_Cnt3 is reset whenever TM_Lmt3 is
written.
Timer 3 can be used as a Watchdog Timer (see Section 12.2).
12.5.4
Timer 4 Counter Register (TM_Cnt4: 0x0035002C)
Bit(s)
15:0
Type
RO
Default
16’b0
Name
TM_Cnt4
Description
Timer 4 Current Counter Value.
Timer 4 increments every 1 µs, from 0 to the Timer 4 limit value, then
resets to 0 and counts again. TM_Cnt4 is reset whenever TM_Lmt4 is
written.
12.5.5
Timer 1 Limit Register (TM_Lmt1: 0x00350030)
Bit(s)
15:0
Type
RW
Default
16’b0
Name
TM_Lmt1
Description
Timer 1 Limit Value.
When the Timer 1 current count reaches this limit value, the
Int_TIMER1 interrupt bit in the Interrupt Status Register (INT_Stat) is
set. The periodic timer interrupt event rate is = 1 MHz / (TM_Lmt1 +
1). If TM_Lmt1 is set to 0, TM_Cnt1 remains reset. TM_Cnt1 is reset
whenever TM_Lmt1 is written.
12.5.6
Timer 2 Limit Register (TM_Lmt2: 0x00350034)
Bit(s)
15:0
Type
RW
Default
16’b0
Name
TM_Lmt2
Description
Timer 2 Limit Value.
When the Timer 2 current count reaches this limit value, the
Int_TIMER2 interrupt bit in the Interrupt Status Register (INT_Stat) is
set. The periodic timer interrupt event rate is = 1 MHz / (TM_Lmt2 +
1). If TM_Lmt2 is set to 0, TM_Cnt2 remains reset. TM_Cnt2 is reset
whenever TM_Lmt2 is written.
