CX82100 Home Network Processor Data Sheet
Bit(s)
15:0;
15≥Y≥0,
Y = Bit #
Type
RR
Default
Name
Description
GPIO[X] Interrupt Status, 31≥X≥16.
See specific GPIO_IS{X},
bit
31≥X≥16,
X = Y+16.
Reading:
bit #Y = 0 = > No interrupt detected on GPIO[X].
bit #Y = 1 = > Interrupt input detected on GPIO[X].
Writing:
0 to bit #Y = > no effect
1 to bit #Y = > clear the interrupt on GPIO[X].
Note: If the interrupt is level-sensitive, the status bit will remain a 1 as
long as the interrupt resource is not removed. The bit can be cleared
only after the resource is removed and a 1 is written to it.
Bit(s)
15
14:12
Type
RR
Default
1’b0
Name
GPIO_IS31
Description
GPIO31 Interrupt Status.
Reserved.
11
10
9
8
7
6
5
4
3
RR
RR
RR
RR
1’b0
1’b0
1’b0
1’b0
GPIO_IS27
GPIO_IS26
GPIO_IS25
GPIO_IS24
GPIO27 Interrupt Status.
GPIO26 Interrupt Status.
GPIO25 Interrupt Status.
GPIO24 Interrupt Status.
Reserved.
GPIO22 Interrupt Status.
GPIO21 Interrupt Status.
GPIO20 Interrupt Status.
GPIO19 Interrupt Status.
GPIO18 Interrupt Status.
GPIO17 Interrupt Status.
GPIO16 Interrupt Status.
RR
RR
RR
RR
RR
RR
RR
1’b0
1’b0
1’b0
1’b0
1’b0
1’b0
1’b0
GPIO_IS22
GPIO_IS21
GPIO_IS20
GPIO_IS19
GPIO_IS18
GPIO_IS17
GPIO_IS16
2
1
0
101306C
Conexant Proprietary and Confidential Information
9-11
