External Components
Figure 2 Recommended External Components
R1 100kΩ
R2 100kΩ
C1 18pF
C2 18pF
C3 10nF
C4 not used
C5 1nF
C6 100pF
C7 100nF
C8 100pF
C9 100pF
C10 not used
C11 See note 5
C12 180pF
C13 See note 5
C14 180pF
C15 See note 5
C16 180pF
C17 10µF
C18 10nF
C19 10nF
C20 10µF
C21 10nF
C22 10nF
C23 10nF
C24 10µF
R3 100kΩ
R4 100kΩ
R5 See note 2
R6 100kΩ
R7 See note 3
R8 100kΩ
X1 3.6864MHz
See note 1
R9 See note 4
R10 100kΩ
