TMC3503
PRODUCT SPECIFICATION
Equivalent Circuits (continued)
V
DD
p
p
R
REF
V
REF
27012B
GND
Figure 4. Equivalent Analog Input Circuit
Absolute Maximum Ratings (beyond which the device may be damaged)1
Parameter
Min
Typ
Max
Unit
Power Supply Voltage
V
DD
(Measured to GND)
-0.5
7.0
V
Inputs
Applied Voltage (measured to GND)2
Forced Current3,4
-0.5
V
V
+ 0.5
V
DD
-10.0
10.0
mA
Outputs
Applied Voltage (measured to GND)2
-0.5
+ 0.5
V
DD
Forced Current3,4
-60.0
60.0
mA
Short Circuit Duration (single output in HIGH state to ground)
infinite
second
Temperature
Operating, Ambient
Junction
-20
110
150
300
220
150
°C
°C
°C
°C
°C
Lead Soldering (10 seconds)
Vapor Phase Soldering (1 minute)
Storage
-65
Notes:
1. Functional operation under any of these conditions is NOT implied. Performance and reliability are guaranteed only if
Operating Conditions are not exceeded.
2. Applied voltage must be current limited to specified range.
3. Forcing voltage must be limited to specified range.
4. Current is specified as conventional current flowing into the device.
6
REV. 1.02 11/24/99
