Enabling and disabling of the clock input must be done when T3/T1/T0 has been stable
for at least one system clock cycle, otherwise it is a risk that a false Timer/Counter clock
pulse is generated.
Each half period of the external clock applied must be longer than one system clock
cycle to ensure correct sampling. The external clock must be guaranteed to have less
than half the system clock frequency (fExtClk < fclk_I/O/2) given a 50/50 % duty cycle.
Since the edge detector uses sampling, the maximum frequency of an external clock it
can detect is half the sampling frequency (Nyquist sampling theorem). However, due to
variation of the system clock frequency and duty cycle caused by Oscillator source
(crystal, resonator, and capacitors) tolerances, it is recommended that maximum fre-
quency of an external clock source is less than fclk_I/O/2.5.
An external clock source can not be prescaled.
Figure 36. Prescaler for Timer/Counter3, Timer/Counter1 and Timer/Counter0(1)
CK
10-BIT T/C PRESCALER
Clear
PSR310
T3
T1
Synchronization
Synchronization
Synchronization
T0
0
0
0
CS00
CS01
CS02
CS10
CS11
CS12
CS30
CS31
CS32
TIMER/COUNTER0 CLOCK SOURCE
TIMER/COUNTER1 CLOCK SOURCE
TIMER/COUNTER3 CLOCK SOURCE
clkT0
clkT1
clkT3
Note:
1. The synchronization logic on the input pins (T0/T1/T3) is shown in Figure 35.
Timer/Counter0/1/3
Prescalers
Register Description
General Timer/Counter
Control Register – GTCCR
Bit
7
TSM
R
6
5
4
3
2
1
PSR2
R/W
0
0
PSR310
R/W
0
GTCCR
Read/Write
Initial Value
R
0
R
0
R
0
R
0
R
0
0
• Bit 7 – TSM: Timer/Counter Synchronization Mode
Writing the TSM bit to one activates the Timer/Counter Synchronization mode. In this
mode, the value that is written to the PSR2 and PSR310 bits is kept, hence keeping the
corresponding prescaler reset signals asserted. This ensures that the corresponding
Timer/Counters are halted and can be configured to the same value without the risk of
one of them advancing during configuration. When the TSM bit is written to zero, the
PSR2 and PSR310 bits are cleared by hardware, and the Timer/Counters start counting
simultaneously.
92
AT90CAN128
4250E–CAN–12/04
