AX88179
USB 3.0 to 10/100/1000M Gigabit Ethernet Controller
JFE: Jumbo Frame Enable.
1: Enable to support 4KB Jumbo frame in Gigabit mode (default).
0: Disabled.
PF: Check only “length/type” field for Pause Frame.
1: Enable. Pause frames are identified only based on L/T filed.
0: Disabled. Pause frames are identified based on both DA and L/T fields (default).
RE: Receive Enable.
1: Enable RX path of the ASIC.
0: Disabled (default).
PS: Port Speed in MII mode
1: 100 Mbps (default).
0: 10 Mbps.
SBP: Stop Backpressure.
1: When TFC bit = 1, setting this bit enables backpressure on TX direction “continuously” during RX buffer full
condition in half duplex mode.
0: When TFC bit = 1, setting this bit enable backpressure on TX direction “intermittently” during RX buffer full
condition in half duplex mode (default).
SM: Super Mac support.
1: Enable Super Mac to shorten exponential back-off time during transmission retrying.
0: Disabled (default).
6.2.2.11 Monitor Mode Status Register (MMSR, 24h, R/W)
Bit7
Bit6
Bit5
Bit4
RW_FLAG
Bit3
RWWF
Bit2
RWMP
Bit1
RWLC
Bit0
0
PME_IND PME_TYPE PME_POL
RWLC: Remote Wakeup riggered by Ethernet Link-change event.
1: Enabled (default).
0: Disabled.
RWMP: Remote Wakeup riggered by Magic Packet event.
1: Enabled (default).
0: Disabled.
RWWF: Remote Wakeup riggered by WakeUp Frame event.
1: Enabled.
0: Disabled (default).
RW_FLAG: Remote Wakeup Enable. It equals EEPROM/RWU-flag AND (logic) Set-Feature (RWU).
1: Enable.
0: Disabled.
PME_POL: PME Polarity.
1: PME active high.
41
