6.2.2.6
Rx Control Register (RCR, 0Bh~0Ch)
Bit7
SO
Bit6
Reserved
Bit5
AP
Reserved
Bit4
AM
Bit3
AB
Bit2
0
TX_CRC_Pad_n
Bit1
AMALL
IPE_n
Bit0
PRO
Drop_CRCE_n
AA [7:0] = {SO, Reserved, AP, AM, AB, 0, AMALL, PRO}
BB [7:0] = {Reserved, TX_CRC_Pad_n, IPE_n, Drop_CRCE_n}
PRO: PACKET_TYPE_PROMISCUOUS. (R/W)
1: All frames received by the ASIC are forwarded up toward the host.
0: Disabled (default).
AMALL: PACKET_TYPE_ALL_MULTICAST. (R/W)
1: All multicast frames received by the ASIC are forwarded up toward the host, not just the frames whose
scrambling result of DA matching with multicast address list provided in Multicast Filter Array Register.
0: Disabled. This only allows multicast frames whose scrambling result of DA field matching with multicast address
list provided in Multicast Filter Array Register to be forwarded up toward the host (default).
AB: PACKET_TYPE_BROADCAST. (R/W)
1: All broadcast frames received by the ASIC are forwarded up toward the host (default).
0: Disabled.
AM: PACKET_TYPE_MULTICAST. (R/W)
1: All multicast frames whose scrambling result of DA matching with multicast address list are forwarded up to the
host (default).
0: Disabled.
AP: Accept Physical Address from Multicast Filter Array. (R/W)
1: Allow unicast packets to be forwarded up toward host if the lookup of scrambling result of DA is found within
multicast address list.
0: Disabled, that is, unicast packets filtering are done without regarding multicast address list (default).
SO: Start Operation. (R/W)
1: Ethernet MAC start operating.
0: Ethernet MAC stop operating (default).
Drop_CRCE_n: Drop CRC field (FCS:4-byte) of RX packet(R/W)
1: Don’t drop CRC field.
0: Drop CRC field (default).
IPE_n: IP alignmemt enable(R/W)
1: IP alignmemt enable (default).
0: IP alignmemt not enable.
TX_CRC_Pad_n: Padding CRC field in TX packet (R/W)
1: No padding CRC field in TX packet.
0: Padding CRC field in TX packet (default).
