AX88179
USB 3.0 to 10/100/1000M Gigabit Ethernet Controller
0: PME active Low (default).
PME_TYP: PME I/O Type.
1: PME output is a Push-Pull driver.
0: PME output to function as an open-drain buffer.
PME_IND: PME indication.
1: A 1.32ms pulse active when detect a wake-up event.
0: A static signal active when detect wake-up event (default).
6.2.2.12 GPIO Status Register (25h, Read)
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
GPO_3_EN GPO_2_EN GPO_1_EN
GPO_0_EN
GPI_3
GPI_2
GPI_1
GPI_0 (PME)
GPO_n_EN: Output enable of GPIO_n. n=0, 1, 2, 3.
1: Output.
0: Input.
GPI_n: Input level on GPIO_n pin when GPIO_n is an input pin. N=0, 1, 2, 3.
Note：If 70h.PME_PIN set to ‘0’, GPI_0 can be indicated as input level on GPIO_0 pin.
If 70h.PME_PIN set to ‘1’, GPI_0 can be indicated as PME output signal value.
6.2.2.13 GPIO Control Register (25h, Write)
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
GPO3EN
GPO2EN
GPO1EN
GPO0EN
GPO_3
GPO_2
GPO_1
GPO_0
GPOnEN: Pin GPIO_n Output Enable. N=0, 1, 2, 3.
1: Output is enabled (meaning GPIO_n is used as an output pin).
0: Output is tri-stated (meaning GPIO_n is used as an input pin) (default).
GPO_n: Pin GPIO_n Output Value. Default value is ‘0’. N=0, 1, 2, 3.
42
