Micro-D Connectors
Solder Cup and Crimp Termination - How to Order
Amphenol
Aerospace
Qualiꢇied to M83513 (slash sheets 01 thru 04)
Series 100, 102 & 104
Example:
100RN09S- 4A5FM2-20
Description: metal shell size 9 rcpt, nickel finish, 26 AWG wire type "A", non-std
wire length 20 inches with M2 low profile jackscrews.
100 R x xxx x - x x x x xx - xxx
Non Std. ꢅength (Inches)
Connector Series
Stranded Wire (no decimal values)
e.g. 1 = 1 inches, 100 = 100 inches
Solid Wire (0.109 < length < 1.00)
e.g. 110 = .110 inches, 999 = .999 inches
100 = metal shell per M83513
102 = all plastic (dimensionally identical
to metal shell per M83513)
104 = stainless steel (dimensionally
identical to metal shell per M83513)
Hardꢆare (pre-installed by factory)
b = standard mounting holes
P = jackpost
ꢀnsulator Material
ꢁ = Polyphenylene Sulfide (Ryton)
M2 = low profile jackscrew, allen head
M3 = high profile jackscrew, allen head
M5 = low profile jackscrew, slot head
M6 = high profile jackscrew, slot head
ꢅ = captive low profile jackscrew
K = captive high profile jackscrew
f = forward float mount
Shell finish Omit for series 102 & 104
A = anodize
C = cadmium
G = gold
ꢀ = irridite/alodine
N = electroless nickel
T = tin
ꢁ = reverse float mount
Connector Siꢉe (number of contacts)
09, 15, 21, 25, 31, 37, 51, 69, 100
All sizes I.A.W. M83513 except size 69 (non-military)
wire ꢅength ((inches +1.00/-0.00)
A = 18.00
b = 36.00
C = 72.00
Connector Type
P = Plug (pin)
S = Receptacle (socket)
D = 0.500 (solid wire only +0.20/-0.00)
ꢃ = 1.00 (solid wire only +0.20/-0.00)
f = Non std. length
Omit for solder cup contacts
wire Siꢉe (AwG.)
1 = 32
2 = 30
wire Color / finish
1 = all white (M83513 standard) *off shelf"
2 = all yellow
3 = 28
4 = 26 (M83513 standard) *off shelf
5 = 25 (solid wire only)
6 = 24
3 = solid wire uninsulated, tin plated
4 = solid wire uninsulated, gold plated
5 = color coded per MIL-STD-681, system 1
6 = 1st 10 colors blk. thru wht. repeated
(M83513 standard) *off shelf
Omit for solder cup contacts
wire Type
Omit for solder cup contacts
General Applications:
A = 7 strd, per NEMA-HP3 (MIL-W-16878/4)
b = 7 strd, per NEMA-HP3 (formerly MIL-W-16878/6)
C = 19 strd, per NEMA-HP3 (formerly MIL-W-16878/4)
D = 19 strd, per NEMA-HP3 (formerly MIL-W-16878/6)
Military/Aerospace Applications:
ꢃ = per MIL-W-22759/11 (M83513 standard)
f = per MIL-W-22759/33 (space grade)
ꢅ = solid wire uninsulated
Features
Plastic and metal shells are intermateable and
intermountable. Available in sizes 9 thru 100,
solder cup or crimp termination. Wide selection
of wire sizes, types, and color finish. Wide
selection of hardware options.
Omit for solder cup contacts
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
