Harnessed Connectors
Series 100, 103 & 104
Amphenol
Aerospace
Qualiꢇied to M83513 (slash sheets 01 thru 04)
WIRE TERMINATION
(M83513/03 & /04)
RECEPTACLE
PLUG
A
B
* INTERFACIAL SEAL NOT INCL. FOR PLASTIC SHELL
THRU HOLE (2 PLCS)
FOR SIZE 9-69
.092
.004 (2.34 0.10)
A
B
FOR SIZE 100
.150/.145 .004 (3.81/3.68 0.10)
E
E
PIN
1
SKT
1
.036/.005 (.92/.12)
.186 (4.73) MAX
.144/.130 (3.66/3.30)
FROM INSUL. SURFACE
C
C
.198 (5.03) MAX
.416 (10.52)
MAX
.429 (10.90)
MAX
REF .093 (2.36)
REF .093 (2.36)
WIRE LENGTH
+1.00/-0.00
WIRE LENGTH
+1.00/-0.00
F
F
SOLDER CUP TERMINATION
PLUG / RECEPTACLE
(M83513/01 & /02)
.110 (2.79)
MAX
.110 (2.79)
MAX
.110 (2.79)
MAX
G
D
G
D
D
G
.200 (5.08)
MAX
.200 (5.08)
MAX
SIZE 9-37
SIZE 100
SIZE 51 & 69
C
MAX
G
MAX
A
MAX
B
D
MAX
E
MAX
F
MAX
SIZE
.005 (0.13)
PLUG
RCPT
PLUG
RCPT
09
15
21
25
31
37
51
69
100
.785 (19.94)
.935 (23.75)
1.085 (27.56)
1.185 (30.10)
1.335 (33.91)
1.485 (37.72)
1.435 (36.45)
1.735 (44.07)
2.170 (55.12)
.565 (14.35)
.715 (18.16)
.865 (21.97)
.965 (24.51)
1.115 (28.32)
1.265 (32.13)
1.215 (30.86)
1.515 (38.48)
1.800 (45.72)
.334 (8.48)
.484 (12.29)
.634 (16.10)
.734 (18.64)
.884 (22.45)
1.034 (26.26)
.984 (24.99)
1.289 (32.74)
1.384 (35.13)
.402 (10.21)
.552 (13.97)
.702 (17.83)
.802 (20.37)
.952 (24.18)
.270 (6.86)
.270 (6.86)
.270 (6.86)
.270 (6.86)
.270 (6.86)
.270 (6.86)
.310 (7.87)
.310 (7.87)
.308 (7.82)
.308 (7.82)
.308 (7.82)
.308 (7.82)
.308 (7.82)
.308 (7.82)
.351 (8.92)
.351 (8.92)
.400 (10.16)
.550 (13.97)
.700 (17.78)
.800 (20.32)
.950 (24.13)
.185 (4.70)
.185 (4.70)
.185 (4.70)
.185 (4.70)
.185 (4.70)
.185 (4.70)
.229 (5.82)
.229 (5.82)
.271 (6.88)
.253 (6.43)
.253 (6.43)
.253 (6.43)
.253 (6.43)
.253 (6.43)
.253 (6.43)
.296 (7.52)
.296 (7.52)
.394 (10.01)
1.102 (27.99)
1.052 (26.72)
1.357 (34.47)
1.508 (38.10)
1.100 (27.94)
1.050 (26.67)
1.350 (34.29)
.360 (9.14) .394 (10.01) 1.442 (36.63)
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
