PCB Connectors
Series 100, 102 & 104 - How to Order
Amphenol
Aerospace
Qualiꢇied to M83513 (slash sheets 10 thru 33)
Example:
100RN21P-CBRP1
Description: Metal shell size 21 plug, nickel finish, CBR termination, PCB
tail lead length .109 inches with jackposts included
100 R x xxx x - BR x x x - xxx
Non Std. wire ꢅength (ꢀnches)
Connector Series
(0.109 < length < 1.00)
e.g. 125 = .125 inches
100 = metal shell per M83513
102 = all plastic (dimensionally identical
to metal shell per M83513)
ꢅead ꢅength (inches)
1 = .109 .015
104 = stainless steel (dimensionally
identical to metal shell per M83513)
2 = .140 .015
3 = .172 .015
ꢀnsulator Material
4 = .250 .015
ꢁ = Polyphenylene Sulfide (Ryton)
f = non std. length
Shell finish Omit for series 102 & 104
A = anodize
C = cadmium
Threaded ꢀnsert (pre-installed)
T = threaded insert (PCB mounting option)
Omit for no threaded insert
G = gold
ꢀ = irridite/alodine
N = electroless nickel
T = tin
Hardꢆare ꢇor bS, bꢁ, Cbꢁ & C6: (pre-installed)
P = jackpost
Omit for no jackpost
Hardꢆare ꢇor C16: (pre-installed)
b = standard mounting holes
M2 = low profile jackscrew, allen head
M3 = high profile jackscrew, allen head
M5 = low profile jackscrew, slot head
M6 = high profile jackscrew, slot head
ꢅ = captive low profile jackscrew
K = captive high profile jackscrew
f = forward float mount
Connector Siꢉe (number of contacts)
09, 15, 21, 25, 31, 37, 51, 69, 100
All sizes I.A.W. M83513 except size 69 (non-military)
Connector Type
P = Plug (pin)
S = Receptacle (socket)
M83513 Ordering Information
Printed Circuit Board Termination:
ꢁ = reverse float mount
M83513/xx - x xx x x
Termination Type
bS = straight PCB per M83513/22 thru /27
bꢁ = 90° PCB per M83513/16 thru /21
Cbꢁ = narrow 90° PCB per M83513/10 thru /15
C6 = straight PCB per M83513/28 thru /33
C16 = straight PCB with flange (C6 PC configuration)
Speciꢇication Sheet
Hardꢆare
N = no jackpost or threaded insert
P = jackpost
10 = plug (pin), CBR type, sizes 9-37
11 = plug (pin), CBR type, size 51
12 = plug (pin), CBR type, size 100
T = threaded insert
13 = receptacle (socket), CBR type, sizes 9-37
14 = receptacle (socket), CBR type, size 51
15 = receptacle (socket), CBR type, size 100
16 = plug (pin), BR type, sizes 9-37
17 = plug (pin), BR type, size 51
w = jackpost and threaded insert
Shell finish
C = cadmium
N = electroless nickel
P = passivated stainless steel
Features
18 = plug (pin), BR type, size 100
• Available in sizes 9 thru 100,
straight and right angle PCB
termination.
19 = receptacle (socket), BR type, sizes 9-37
20 = receptacle (socket), BR type, size 51
21 = receptacle (socket), BR type, size 100
22 = plug (pin), BS type, sizes 9-37
23 = plug (pin), BS type, size 51
24 = plug (pin), BS type, size 100
25 = receptacle (socket), BS type, sizes 9-37
26 = receptacle (socket), BS type, size 51
27 = receptacle (socket), BS type, size 100
28 = plug (pin), C6 type, sizes 9-37
ꢅead ꢅength (inches)
01 = .109 .015
02 = .140 .015
03 = .172 .015
• Solid copper 24 AWG PCB leads,
tin plated, and solder dipped.
• Wide selection of hardware
options.
• Consult Amphenol Aerospace for
other wire size termination.
ꢀnsert Arrangement
A = 9
b = 15
C = 21
29 = plug (pin), C6 type, size 51
D = 25
30 = plug (pin), C6 type, size 100
ꢃ = 31
31 = receptacle (socket), C6 type, sizes 9-37
32 = receptacle (socket), C6 type, size 51
33 = receptacle (socket), C6 type, size 100
f = 37
G = 51 (applicable for spec sheet 11, 14, 17, 20, 23, 26, 29 & 32)
H = 100 (applicable for spec sheet 12, 15, 18, 21, 24, 27, 30 & 33)
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
149
