PCB Connectors
Series 100, 102 & 104
Qualiꢇied to M83513 (slash sheets 22 thru 27)
Amphenol
Aerospace
bS STꢁAꢀGHT PCb CꢂNfꢀGꢄꢁATꢀꢂNS
.
PLUG
RECEPTACLE
THRU HOLE (2 PLCS)
* INTERFACIAL SEAL NOT INCL. FOR PLASTIC SHELL
FOR SIZE 9-69
A
B
C
.096 .003 (2.44 0.08)
FOR SIZE 100
.125 .003 (3.18 0.08)
A
B
C
G
F
F
G
PIN 1
JACKPOST (2 PLCS)
#2-56 UNC-2B (SIZE 9-69)
#4-40 UNC-2B (SIZE 100)
SKT 1
D
E
FOR SIZE 9-69
.190 (4.82) MAX
FOR SIZE 100
.185 (4.69) MAX
D
E
.198 (5.03) MAX
.186 (4.72) MAX
J
J
H
H
LEAD LENGTH
.015
LEAD LENGTH
.015
.020 TYP.
.020 TYP.
E
MAX
F
MAX
A
MAX
B
C
D
MAX
G
MAX
H
MAX
J
SIZE
.005 (0.13)
.005 (0.13)
MAX
PLUG
RCPT
PLUG
RCPT
09
15
21
25
31
37
51
69
1.390 (35.31) 1.150 (29.21) .565 (14.35)
1.390 (35.31) 1.150 (29.21) .715 (18.16)
.785 (19.84)
.935 (23.75)
.334 (8.48)
.402 (10.21) .185 (4.70) .253 (6.43)
.308 (7.82) .165 (4.19) .355 (9.02)
.308 (7.82) .165 (4.19) .355 (9.02)
.308 (7.82) .165 (4.19) .355 (9.02)
.308 (7.82) .165 (4.19) .355 (9.02)
.308 (7.82) .165 (4.19) .355 (9.02)
.308 (7.82) .165 (4.19) .355 (9.02)
.351 (8.92) .165 (4.19) .355 (9.02)
.351 (8.92) .165 (4.19) .355 (9.02)
.484 (12.29) .552 (13.97) .185 (4.70) .253 (6.43)
.634 (16.10) .702 (17.83) .185 (4.70) .253 (6.43)
.734 (18.64) .802 (20.37) .185 (4.70) .253 (6.43)
1.690 (43.93) 1.450 (36.83) .865 (21.97) 1.085 (27.56)
1.740 (44.20) 1.500 (38.10) .965 (24.51) 1.185 (30.10)
2.040 (51.82) 1.800 (45.72) 1.115 (28.32) 1.335 (33.91) .884 (22.45) .952 (24.18) .185 (4.70) .253 (6.43)
2.340 (59.44) 2.100 (53.34) 1.265 (32.13) 1.485 (37.72) 1.034 (26.26) 1.102 (27.99) .185 (4.70) .253 (6.43)
2.270 (67.66) 2.000 (50.80) 1.215 (30.86) 1.435 (36.45) .984 (24.99) 1.052 (26.72) .228 (5.79) .296 (7.52)
2.870 (72.90) 2.600 (66.04) 1.515 (38.48) 1.735 (44.07) 1.289 (32.74) 1.357 (34.47) .228 (5.79) .296 (7.52)
100 3.070 (77.98) 2.800 (71.12) 1.800 (45.72) 2.170 (55.12) 1.384 (35.13) 1.508 (38.10) .271 (6.88) .394 (10.01) .460 (11.68) .303 (7.70) .550 (12.70)
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
150
