N
N
N
N
•
•
•
Rcv Descriptor
Ring
1st
2nd
desc.
start
desc.
CSR2
CSR1
start
IADR[31:16]
IADR[15:0]
RMD
RMD
RMD
RMD
RMD
Initialization
Block
TLE RES RLE RES
MODE
Data
Buffer
1
Data
Buffer
2
Data
Buffer
N
Rcv
Buffers
PADR[31:0]
PADR[47:32]
RES
LADRF[31:0]
LADRF[63:32]
RDRA[31:0]
TDRA[31:0]
M
M
M
M
•
•
•
Xmt Descriptor
Ring
1st
desc.
start
2nd
desc.
start
TMD0
TMD0
TMD3
TMD1
TMD2
Data
Buffer
M
Data
Buffer
1
Data
Buffer
2
Xmt
Buffers
22206B-37
Figure 34. 32-Bit Software Model
Polling
CSR19, CSR20, CSR21, CSR40, CSR42, CSR50,
CSR52).
If there is no network channel activity and there is no
pre- or post-receive or pre- or post-transmit activity
being performed by the Am79C978 controller, then the
Am79C978 controller will periodically poll the current
receive and transmit descriptor entries in order to as-
certain their ownership. If the DPOLL bit in CSR4 is set,
then the transmit polling function is disabled.
A typical receive poll is the product of the following con-
ditions:
1. The controller does not own the current RDTE and
the poll time has elapsed and RXON = 1 (CSR0,
bit 5), or
2. The controller does not own the next RDTE and
there is more than one receive descriptor in the ring
and the poll time has elapsed and RXON = 1.
A typical polling operation consists of the following se-
quence. TheAm79C978 controller will use the current
receive descriptor address stored internally to vector to
the appropriate Receive Descriptor Table Entry
(RDTE). It will then use the current transmit descriptor
address (stored internally) to vector to the appropriate
Transmit Descriptor Table Entry (TDTE). The accesses
will be made in the following order: RMD1, then RMD0
of the current RDTE during one bus arbitration, and
after that, TMD1, then TMD0 of the current TDTE dur-
ing a second bus arbitration. All information collected
during polling activity will be stored internally in the ap-
propriate CSRs, if the OWN bit is set (i.e., CSR18,
If RXON is cleared to 0, the Am79C978 controller will
never poll RDTE locations.
In order to avoid missing frames, the system should
have at least one RDTE available. To minimize poll ac-
tivity, two RDTEs should be available. In this case, the
poll operation will only consist of the check of the status
of the current TDTE.
A typical transmit poll is the product of the following
conditions:
62
Am79C978
