D A T A S H E E T
ORDERING INFORMATION
Standard Products
AMD standard products are available in several packages and operating ranges. The order number (Valid Combination) is
formed by a combination of the following:
Am29F016D -70
E
I
TEMPERATURE RANGE
C
D
I
=
=
=
=
Commercial (0°C to +70°C)
Commercial (0°C to +70°C) with Pb-free package
Industrial (–40°C to +85°C)
F
Industrial (–40°C to +85°C)with Pb-free package
PACKAGE TYPE
E
=
=
=
48-Pin Thin Small Outline Package (TSOP) Standard Pinout (TS 048)
E4
S
40-Pin Thin Small Outline Package (TSOP) Standard Pinout (TS 040)
44-Pin Small Outline Package (SO 044)
This device is also available in Known Good Die (KGD) form. See publication number
21551 for more information.
SPEED OPTION
See Product Selector Guide and Valid Combinations
DEVICE NUMBER/DESCRIPTION
Am29F016D
16 Megabit (2 M x 8-Bit) CMOS 5.0 Volt-only Sector Erase Flash Memory
5.0 V Read, Program, and Erase
Valid Combinations
Valid Combinations
Valid Combinations list configurations planned to be sup-
ported in volume for this device. Consult the local AMD sales
office to confirm availability of specific valid combinations and
to check on newly released combinations.
EC, EI, ED, EF, E4D, E4F,
SD, SF, E4C, E4I, SC, SI
AM29F016D-70
AM29F016D-90
AM29F016D-120
EC, EI, E4C, E4I, SC, SI, ED,
EF, E4D, E4F, SD, SF
November 1, 2006 21444E6
Am29F016D
7
