S5920 – PCI Product: Electrical Characteristics
Data Book
PCI Signal DC Characteristics
The following table summarizes the DC characteristic parameters for all PCI signals listed below as they apply to
the S5920.
AD[31:0] (t/s), PAR (t/s), C/BE[3:0]# (in), FRAME# (in), IRDY# (in), TRDY# (s/t/s), STOP# (s/t/s), LOCK# (in),
IDSEL (in), DEVSEL# (s/t/s), PERR# (s/t/s), SERR# (o/d), INTA# (o/d), RST# (in), CLK (in).
Table 61. PCI Signal DC Characteristics (V = 5.0V 5%, 0°C to 70°C, 50 pF load on outputs)
CC
Symbol
Parameter
Input High Voltage
Min
Max
Units
Test Conditions
Notes
V
V
L
2.0
-
Volts
1
IH
IL
-0.5
0.8
70
-70
-
Volts
uA
1
2
2
Input Low Voltage
-
-
V
V
I
= 2.7
Input High Leakage Current
Input Low Leakage Current
Output High Voltage
IH
IL
IN
IN
L
uA
= 0.5
V
V
2.4
-
Volts
Volts
pF
= -2 mA
OH
OL
OUT
OUT
0.55
10
12
8
I
= 3 mA, 6 mA
3
4
Output Low Voltage
C
C
C
-
Input Pin Capacitance
CLK Pin Capacitance
IDSEL Pin Capacitance
IN
5
-
pF
CLK
IDSEL
pF
Notes:
1. Recommended values for all PCI signals except CLK to be Vih = 2.4 Min and Vil = .4 Max.
2. Input leakage applies to all inputs and bi-directional buffers.
3. PCI bus signals without pull-up resistors will provide the 3 mA output current. Signals which require a pull-up resistor will provide 6 mA output
current.
4. The PCI specification limits all PCI inputs not located on the motherboard to 10 pF (the clock is allowed to be 12 pF).
