S5920 – PCI Product: Electrical Characteristics
ABSOLUTE MAXIMUM STRESS RATINGS
Data Book
Table 1 lists the absolute maximum S5920 device stress ratings. Stresses beyond those listed may cause perma-
nent damage to the device. These are stress ratings only; operation of the device at these or any other conditions
beyond those indicated in the Operating Characteristics section of this specification is not implied.
Table 59. Absolute Maximum Stress Ratings
Parameter
Min
-55
Max
125
Units
°C
Storage Temperature
Supply Voltage (V DD)
Input Pin Voltage
- 0.3
- 0.5
7.0
Volts
Volts
GND + 5.0
S5920 Operating Conditions
Table 2 lists the S5920 operating conditions. These parameters are guaranteed by device characterization, but not
device tested. All values are maximum guaranteed values.
Table 60. Operating Conditions
Symbol
Parameter
Supply Voltage
Min
Max
Units
Test Conditions
Notes
V
4.75
5.25
V
CC
I
I
- 49 mA
- 197 mA
0
V
V
= 5.25
V
V
Supply Current (Static)
Supply Current (Dynamic)
Operating Temperature
Thermal Resistance
Power Dissipation
CC
CC
CC
CC
= 5.25
70
T
°C
A
0
- TBD
TBD
°C/W
W
JA
P
0
V CC = 5.25 Volts
DD
