[AK4679]
Input Frequency
MCKI[MHz]
Sampling Frequency
Mode
Sampling Frequency
generated by PLL [kHz](Note 75)
11.2896
8kHz mode
12kHz mode
16kHz mode
24kHz mode
32kHz mode
48kHz mode
11.025kHz mode
22.05kHz mode
44.1kHz mode
8.000000
12.000000
16.000000
24.000000
32.000000
48.000000
11.025000
22.050000
44.100000
12
8kHz mode
12kHz mode
16kHz mode
24kHz mode
32kHz mode
48kHz mode
11.025kHz mode
22.05kHz mode
44.1kHz mode
8.000000
12.000000
16.000000
24.000000
32.000000
48.000000
11.024877
22.049753
44.099507
24
8kHz mode
12kHz mode
16kHz mode
24kHz mode
32kHz mode
48kHz mode
11.025kHz mode
22.05kHz mode
44.1kHz mode
8.000000
12.000000
16.000000
24.000000
32.000000
48.000000
11.024877
22.049753
44.099507
13.5
8kHz mode
12kHz mode
16kHz mode
24kHz mode
32kHz mode
48kHz mode
11.025kHz mode
22.05kHz mode
44.1kHz mode
8.000300
12.000451
16.000601
24.000901
32.001202
48.001803
11.025218
22.050436
44.100871
27
8kHz mode
12kHz mode
16kHz mode
24kHz mode
32kHz mode
48kHz mode
11.025kHz mode
22.05kHz mode
44.1kHz mode
8.000300
12.000451
16.000601
24.000901
32.001202
48.001803
11.025218
22.050436
44.100871
Sampling frequency that differs from sampling frequency of mode name
Note 75. These are rounded off to six decimal places.
Table 7. Sampling Frequency at PLL mode (Reference clock is MCKI)
