Typical Performance Characteristics
Mean Resolution vs Z
600
500
400
300
200
100
Black Formica
White Melamine bookshelf
Manila
White paper
0
Distance from Lens Reference Plane to Surface, Z (mm)
Figure 10. Mean Resolution vs. Z (White Paper).
Typical Path Deviation
Largest Single Perpendicular Deviation From A Straight Line At 45 Degrees
Path Length = 4 inches; Speed = 6 ips ; Resolution = 400 cpi
60
50
40
30
20
10
0
Black Formica
White Melamine bookshelf
Manila
White paper
Distance From Lens Reference Plane To Navigation Surface (mm)
Figure 11. Average error vs. distance (mm)
Relative Responsivity for ADNS-3040
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
400
500
600
700
800
900
1000
Wavelength (nm)
Figure 12. Relative Responsivity
10
