Regulatory Requirements
• Passes IEC-1000-4-3
radiated susceptibility level
when assembled into a
mouse with shielded cable
and following Agilent
recommendations.
• UL flammability level UL94
V-0.
• Passes FCC B and
worldwide analogous
emission limits when
assembled into a mouse
with shielded cable and
following Agilent
• Provides sufficient ESD
creepage/clearance distance
to avoid discharge up to
15kV when assembled into a
mouse according to usage
instructions above.
• Passes EN61000-4-4/IEC801-
4 EFT tests when assembled
into a mouse with shielded
cable and following Agilent
recommendations.
recommendations.
Absolute Maximum Ratings
Parameter
Symbol Minimum
Maximum
Units
°C
Notes
Storage Temperature
TS
-40
85
Lead Solder Temp
260
°C
For 10 seconds, 1.6mm below
seating plane.
Supply Voltage
ESD
VDD
-0.5
-0.5
3.7
2
V
kV
All pins, human body model MIL 883
Method 3015
Input Voltage
VIN
VDD+0.5
20
V
All Pins
All Pins
Latchup Current
IOUT
mA
Recommended Operating Conditions
Parameter
Symbol Minimum Typical Maximum Units
Notes
Operating Temperature
TA
0
40
°C
Power supply voltage - for
HLMP-ED80-PS000 LED *
VDD
2.6
3.6
Volts
Including noise.
0 to 2.6V
Power supply rise time
Supply noise(Sinusoidal)
Serial Port Clock Frequency
VRT
VNA
fSCLK
Z
0.001
2.3
100
100
1
ms
mV p-p 10kHz-50MHz
MHz
mm
Active drive, 50% duty cycle.
Distance from lens reference
plane to surface
2.4
2.5
Results in 0.2 mm DOF, See
drawing below
Speed
S
20
8
in/sec
G
Acceleration
Load Capacitance
A
COUT
100
pF
MOTION, MISO
* Please note that for HSDL-4261 IR LED, the min power supply is 2.5V.
Sensor
Lens
2.40
0.094
Object Surface
Figure 9. Distance from lens reference plane to surface
7
