• TRG reset synchronous generation --- 525-line mode
Mode setting conditions: VMD[1:0] = 0, ASYNC = 1, INT = 0, SVDL[10:0] = n
[Setting VSYM[0] = 0]
For external TRG input, one vertical Sync. signal of 3 lines is generated in OVS following 3 lines from the delay
adjustment position by SVDL[10:0] and one vertical Sync. signal of 3 lines is generated following 262.5 lines.
[Setting VSYM[0] = 1]
For external TRG input, one vertical Sync. signal of 1.5 lines is generated following 4 lines from the delay
adjustment position by SVDL[10:0] and one vertical Sync. signal of 1.5 lines is generated following 262.5 lines.
The value that is set in SVDL[10:0] must be less than (number of lines per frame (525) x 2).
Under the default condition (SFINV(SUB:68h-bit[2]) = 0), Sync. signals are generated twice for TRG input in
the sequence of field A and field B and under SFINV = 1, Sync. signals are generated twice in the sequence of
field A and field B.
SVDL[10:0]
TRG
[SFINV=0]
OHS
[SFINV=1]
OHS
262.5 lines
[VSYM[0]=0,OVSINV=0]
OVS
3 lines
3 lines
3 lines
3 lines
[VSYM[0]=0,OVSINV=1]
OVS
262.5 lines
[VSYM[0]=1,OVSINV=0]
OVS
4 lines
1.5 lines
4 lines
1.5 lines
[VSYM[0]=1,OVSINV=1]
OVS
TRG reference position
OVS reset position
Figure F3-1-3(8) Vertical Direction Timing 6
