EAGLE
13
PRELIMINARY
Input Video Sync. Select at Remote mode
Ver 1.3
R/W
0b
: 0 = No Input
: 1 = H(V)SYNC - Digital, Decoder Input
12
11
10
9
R/W
R/W
R/W
R/W
R/W
H(V)SYNC Input Polarity at Remote mode(when reg. 13 bit, ‘1’)
0b
0b
0b
0b
0b
: 0 = High Active
Field signal (not) use at Remote mode(when reg. 13 bit, ‘1’)
: 0 = Use 1 = not use
Field(Odd Field) Input Polarity at Remote mode(when reg. 13 bit, ‘1’)
: 0 = when Odd Field is ‘1’ 1 = when Odd Field is ‘0’
VSYNC. Output Select at Remote Mode.
1 = Low Active
: 0 = Internal Block
1 = VSYNCIN(External Pin)
8
HSYNC. Output Select at Remote Mode.
: 0 = Internal Block
1 = HSYNCIN(External Pin)
# TV, VGA(LCD) mode register #
7
6
5
4
R/W
R/W
R/W
R/W
TV/VGA mode Enable.
: 0 = VGA(LCD) mode
Interlace Enable.
: 0 = Non-interlace mode
Horizontal Scan Line Number
: 0 = 525line
0b
0b
0b
0b
1 = TV mode
1=Interlace mode
1 = 625line
Color Burst Frequency
: 0 = 3.58Mhz
1 = 4.43Mhz
# Display mode register #
3
R/W
R/W
R/W
Vertical Double Scan Enable.
: 0 = Disable
Horizontal Double Scan Enable.
: 0 = Disable
Screen Display Mode Control.
: 00=Normal operation.
0b
0b
1 = Enable
1 = Enable
2
1-0
00b
: 01=Regular Pattern Generation
: 1x=Screen off
Beijing Peak Microtech Co.Ltd.
CONFIDENTIAL
