3.5.6 Interrupt Priority Programmable Register (INPPRn)
The INPPR registers enable interrupt priority to be programmed. Default interrupt priority is changed by setting the
INPPR registers. INTMOD[31] bit controls the priority program capability. Software must set the INTMOD[31] bit to ‘1’
before programming the INPPR registers. Setting the INTMOD[31] bit to ‘0’ immediately reverts the interrupt priority back
to the default configuration.
Interrupt Priority Programmable Register 0 (INPPR0)
Address : FFE0 0C14h
Bit
R/W
R
R/W
R
R/W
R
R/W
R
Description
Default Value
31 : 29
28 : 24
23 : 21
20 : 16
15 : 13
12 : 8
7 : 5
Reserved
3rd Interrupt Source Number
Reserved
2nd Interrupt Source Number
Reserved
1st Interrupt Source Number
Reserved
-
00011b
-
00010b
-
00001b
-
4 : 0
R/W
0th Interrupt Source Number (Highest priority)
00000b
Interrupt Priority Programmable Register 1 (INPPR1)
Address : FFE0 0C18h
Bit
R/W
R
R/W
R
R/W
R
R/W
R
Description
Description
Description
Default Value
31 : 29
28 : 24
23 : 21
20 : 16
15 : 13
12 : 8
7 : 5
Reserved
7th Interrupt Source Number
Reserved
6th Interrupt Source Number
Reserved
5th Interrupt Source Number
Reserved
-
00111b
-
00110b
-
00101b
-
4 : 0
R/W
4th Interrupt Source Number
00100b
Interrupt Priority Programmable Register 2 (INPPR2)
Address : FFE0 0C1Ch
Bit
R/W
R
R/W
R
R/W
R
R/W
R
Default Value
31 : 29
28 : 24
23 : 21
20 : 16
15 : 13
12 : 8
7 : 5
Reserved
11th Interrupt Source Number
Reserved
10th Interrupt Source Number
Reserved
9th Interrupt Source Number
Reserved
-
01011b
-
01010b
-
01001b
-
4 : 0
R/W
8th Interrupt Source Number
01000b
Interrupt Priority Programmable Register 3 (INPPR3)
Address : FFE0 0C20h
Bit
R/W
R
R/W
R
R/W
R
R/W
R
Default Value
31 : 29
28 : 24
23 : 21
20 : 16
15 : 13
12 : 8
7 : 5
Reserved
15th Interrupt Source Number
Reserved
14th Interrupt Source Number
Reserved
13th Interrupt Source Number
Reserved
-
01111b
-
01110b
-
01101b
-
4 : 0
R/W
12th Interrupt Source Number
01100b
