Cable Assembly Instruction Y
Solder-clamp
STEP 1.
STEP 2.
All parts of the connector are shown.
Strip the cable inner conductor, dielectric, braid, and jacket as per
"RECOMMENDED CABLE STRIPPING DIM'S" in catalog.
STEP 3.
STEP 4.
STEP 5.
Slide the NUT onto cable, then insert inner conductor into the
CONTACT PIN and solder it, fold back braid wire as shown.
Place the BRAID CLAMP over braid and push back against
cable jacket.
Insert cable and parts into the MAIN BODY, then screw the
NUT until it is tightened.
