ST6200C/ST6201C/ST6203C
12 GENERAL INFORMATION
12.1 PACKAGE MECHANICAL DATA
Figure 74. 16-Pin Plastic Dual In-Line Package, 300-mil Width
mm
Min Typ Max Min Typ Max
5.33 0.210
inches
Dim.
A
A1 0.38
0.015
A2 2.92 3.30 4.95 0.115 0.130 0.195
b
b2
c
0.36
0.56 0.014
1.52 1.78
0.022
0.060 0.070
0.20 0.25 0.36 0.008 0.010 0.014
18.67 19.18 19.69 0.735 0.755 0.775
D
e
2.54
0.100
E1 6.10 6.35 7.11 0.240 0.250 0.280
L
2.92 3.30 3.81 0.115 0.130 0.150
Number of Pins
PDIP16
N
16
Figure 75. 16-Pin Plastic Small Outline Package, 300-mil Width
mm
inches
Typ
Dim.
Min Typ Max Min
Max
A
2.35
2.65 0.0926
0.0040
0.1043
A1 0.10
B
C
D
E
e
0.33
0.51 0.013
0.32
0.020
0.0125
0.4133
0.2992
10.10
7.40
10.50 0.3977
7.60 0.2914
1.27
0.050
H
h
10.01
0.25
0°
10.64 0.394
0.74 0.010
0.419
0.029
8°
K
L
8°
0°
0.41
1.27 0.016
0.10
0.050
0.004
G
SO16
Number of Pins
N
16
89/104
