IP1001 LF
Data Sheet
MII/GMII/RGMII selection and signal direction
RGMII is active if pin 36 RGMII_N/GMII is pulled low.
TD[3:0]
TXD[3:0]
TX_ER
TXCTL
TXC
TXEN/ TXCTL
GTX_CLK/ TXC
RXD[3:0]
RXD[3:0]
RX_ER
IP1001
MAC
MAC
MAC
MDI[3:0]P/M
transformer
RXCTL
RXC
RXDV/ RXCTL
CRS
COL
RX_CLK/ RXC
TX_CLK
GMII is active if pin 15 RGMII_N/GMII is pulled high and IP1001is linked at giga mode.
TXD[7:0]
TXER
TXD[7:0]
TX_ER
TXEN
TXEN/ TXCTL
GTX_CLK/ TXC
GTX_CLK
RXD[7:0]
RXER
RXD[7:0]
IP1001
RX_ER
RXDV/ RXCTL
CRS
MDI[3:0]P/M
transformer
RXDV
CRS
COL
COL
RX_CLK/ RXC
TX_CLK
RXCLK
MII is active if pin 15 RGMII_N/GMII is pulled high and IP1001 islinked at 100M, or 10M.
TXD[3:0]
TXER
TXD[3:0]
TX_ER
TXEN
TXEN/ TXCTL
GTX_CLK/ TXC
RXD[3:0]
RXER
RXDV
CRS
RXD[3:0]
IP1001
RX_ER
RXDV/ RXCTL
CRS
MDI[3:0]P/M
transformer
COL
COL
RX_CLK/ RXC
TX_CLK
RXCLK
TXCLK
