IP1001 LF
Data Sheet
LED application circuit
Mode 0 & mode 2
LED
R2
220 ohm
LED 0,1,2
Mode 1
LED0
LED1
R51 220
1
2
LED
R2
LED 2
Bi-color
220 ohm
Bi-color LED
configuration
Mode 3
VDDO
R51
220
LED4
Bi-tripple color
LED
R2
LED 2
LED0
LED1
220 ohm
Bi-tripple color LED
configuration
Mode0
0,0
Mode1
0,1
Mode2
Mode3
LED_MODE1,
LED_MODE0
1,0
1,1
Pin 13 LED0
Pin 14 LED1
10/100M Link/Act Bi-color mode
1G Link/ Act
Bi-triple-color mode
{LED0, LED1}=
10= 1G Link;
01= 100M Link
00= 10M Link;
11= link off
{LED0, LED1}=
100M Link/Act
100M Link/ Act
10M Link/ Act
10= 1G Link;
01=10/100M Link;
00= link off
11= link off
Pin 15 LED2
1G Link/Act
Act
Link/ Act
Note:
Link: LED on
Act (activity): LED blinking (frequency is about 10Hz)
21/48
Dec. 18, 2007
IP1001-DS-R06
Copyright © 2006, IC Plus Corp.
