Data Sheet
June 1999
ORCA Series 2 FPGAs
+ (0.022 mW/MHz – PFU) (# PFUs)
+ (0.006 mW/MHz – SMEM_PFU)
(# SMEM_PFUs)] fCLK
Estimating Power Dissipation (continued)
OR2C06A Clock Power
For a quick estimate, the worst-case (typical circuit)
OR2C26A clock power ≈ 17.8 mW/MHz.
P
= [0.63 mW/MHz
+ (0.25 mW/MHz – Branch) (# Branches)
+ (0.022 mW/MHz – PFU) (# PFUs)
+ (0.006 mW/MHz – SMEM_PFU)
(# SMEM_PFUs)] fCLK
OR2C40A Clock Power
P
= [0.77 mW/MHz
+ (0.53 mW/MHz – Branch) (# Branches)
+ (0.022 mW/MHz – PFU) (# PFUs)
+ (0.006 mW/MHz – SMEM_PFU)
(# SMEM_PFUs)] fCLK
For a quick estimate, the worst-case (typical circuit)
OR2C06A clock power ≈ 5.3 mW/MHz.
OR2C08A Clock Power
P
= [0.65 mW/MHz
For a quick estimate, the worst-case (typical circuit)
+ (0.29 mW/MHz – Branch) (# Branches)
+ (0.022 mW/MHz – PFU) (# PFUs)
+ (0.006 mW/MHz – SMEM_PFU)
(# SMEM_PFUs)] fCLK
OR2C40A clock power ≈ 26.6 mW/MHz.
The power dissipated in a PIC is the sum of the power
dissipated in the four I/Os in the PIC. This consists of
power dissipated by inputs and ac power dissipated by
outputs. The power dissipated in each I/O depends on
whether it is configured as an input, output, or input/
output. If an I/O is operating as an output, then there is
a power dissipation component for PIN, as well as
POUT. This is because the output feeds back to the
input.
For a quick estimate, the worst-case (typical circuit)
OR2C08A clock power ≈ 6.6 mW/MHz.
OR2C10A Clock Power
P
= [0.66 mW/MHz
+ (0.32 mW/MHz – Branch) (# Branches)
+ (0.022 mW/MHz – PFU) (# PFUs)
+ (0.006 mW/MHz – SMEM_PFU)
(# SMEM_PFUs)] fCLK
The power dissipated by a TTL input buffer is estimated
as:
PTTL = 2.2 mW + 0.17 mW/MHz
For a quick estimate, the worst-case (typical circuit)
OR2C10A clock power ≈ 8.6 mW/MHz.
The power dissipated by an input buffer is estimated
as:
OR2C12A Clock Power
PCMOS = 0.17 mW/MHz
P
= [0.68 mW/MHz
The ac power dissipation from an output or bidirec-
tional is estimated by the following:
+ (0.35 mW/MHz – Branch) (# Branches)
+ (0.022 mW/MHz – PFU) (# PFUs)
+ (0.006 mW/MHz – SMEM_PFU)
(# SMEM_PFUs)] fCLK
2
POUT = (CL + 8.8 pF) x VDD x F Watts
where the unit for CL is farads, and the unit for F is Hz.
For a quick estimate, the worst-case (typical circuit)
OR2C12A clock power ≈ 10.5 mW/MHz.
As an example of estimating power dissipation,
suppose that a fully utilized OR2C15A has an average
of three outputs for each of the 400 PFUs, that all
20 clock branches are used, that 150 of the 400 PFUs
have FFs clocked at 40 MHz (16 of which are operating
in a synchronous memory mode), and that the PFU
outputs have an average activity factor of 20%.
OR2C15A Clock Power
P
= [0.69 mW/MHz
+ (0.38 mW/MHz – Branch) (# Branches)
+ (0.022 mW/MHz – PFU) (# PFUs)
+ (0.006 mW/MHz – SMEM_PFU)
(# SMEM_PFUs)] fCLK
Twenty TTL-configured inputs, 20 CMOS-configured
inputs, 32 outputs driving 30 pF loads, and 16 bidirec-
tional I/Os driving 50 pF loads are also generated from
the 40 MHz clock with an average activity factor of
20%. The worst-case (VDD = 5.25 V) power dissipation
is estimated as follows:
For a quick estimate, the worst-case (typical circuit)
OR2C15A clock power ≈ 12.7 mW/MHz.
OR2C26A Clock Power
PPFU = 400 x 3 (0.16 mW/MHz x 20 MHz x 20%)
= 768 mW
P
= [0.73 mW/MHz
+ (0.44 mW/MHz – Branch) (# Branches)
62
Lucent Technologies Inc.
