ORCA Series 2 FPGAs
Timing Characteristics (continued)
Table 40A. OR2CxxA and OR2TxxA Synchronous Memory Read Characteristics (SSPM and SDPM Modes)
OR2CxxA Commercial: VDD = 5.0 V ± 5%, 0 °C ≤ TA ≤ 70 °C; OR2CxxA Industrial: VDD = 5.0 V ± 10%, –40 °C ≤ TA ≤ +85 °C.
OR2TxxA Commercial: VDD = 3.0 V to 3.6 V, 0 °C ≤ TA ≤ 70 °C; OR2TxxA Industrial: VDD = 3.0 V to 3.6 V, –40 °C ≤ TA ≤
+85 °C.
Speed
Unit
Parameter
Symbol
-2
-3
-4
-5
-6
-7
Min Max Min Max Min Max Min Max Min Max Min Max
Read Operation (TJ = 85 °C, VDD = min):
Read Cycle Time
Data Valid After Address
(A[3:0], B[3:0] to F[3:0])
TRC
MEMS*_ADEL
5.1
—
—
4.0
3.6
—
—
2.8
2.7
—
—
2.1
2.4
—
—
1.7
2.3
—
—
1.4
2.0
—
—
1.1
ns
ns
Read Operation, Clocking Data Into
Latch/FF (TJ = 85 °C, VDD = min):
Address to Clock Setup Time
(A[3:0], B[3:0] to CK)
Clock to PFU Output—Register
(CK to Q[3:0])
MEMS*_ASET 2.4
REG_DEL
—
1.8
—
—
1.2
—
—
1.1
—
—
1.0
—
—
0.9
—
—
ns
ns
—
2.4
2.0
1.9
1.5
1.3
1.0
Note: Speed grades of -5, -6, and -7 are for OR2TxxA devices only.
Table 40B. OR2TxxB Synchronous Memory Read Characteristics (SSPM and SDPM Modes)
OR2TxxB Commercial: VDD = 3.0 V to 3.6 V, 0 °C ≤ TA ≤ 70 °C; OR2TxxB Industrial: VDD = 3.0 V to 3.6 V, –40 °C ≤ TA ≤
+85°C.
Speed
Unit
Parameter
Symbol
-7
-8
Min
Max
Min
Max
Read Operation (TJ = 85 °C, VDD = min):
Read Cycle Time
Data Valid After Address
(A[3:0], B[3:0] to F[3:0])
TRC
MEMS*_ADEL
1.9
—
—
1.8
1.8
—
—
1.4
ns
ns
Read Operation, Clocking Data into
Latch/FF (TJ = 85 °C, VDD = Min):
Address to Clock Setup Time
(A[3:0], B[3:0] to CK)
Clock to PFU Output—Register
(CK to Q[3:0])
MEMS*_ASET
REG_DEL
0.9
—
—
0.8
—
—
ns
ns
1.0
1.0
A[3:0], B[3:0]
F[3:0]
MEM*_ADEL
MEM*_ASET
CK
REG_DEL
Q[3:0]
5-4622(F).r2.a
Figure 61. Synchronous Memory Read Cycle
