Data Sheet
June 1999
ORCA Series 2 FPGAs
Timing Characteristics (continued)
Table 38A. OR2CxxA and OR2TxxA Asynchronous Memory Read During Write, Clocking Data into Latch/
Flip-Flop (MA/MB Modes)
OR2CxxA Commercial: VDD = 5.0 V ± 5%, 0 °C ≤ TA ≤ 70 °C; OR2CxxA Industrial: VDD = 5.0 V ± 10%, –40 °C ≤ TA ≤ +85 °C.
OR2TxxA Commercial: VDD = 3.0 V to 3.6 V, 0 °C ≤ TA ≤ 70 °C; OR2TxxA Industrial: VDD = 3.0 V to 3.6 V, –40 °C ≤ TA ≤
+85 °C.
Speed
Parameter
Symbol
Unit
-2
-3
-4
-5
-6
-7
Min Max Min Max Min Max Min Max Min Max Min Max
Setup Time (TJ = 85 °C, VDD = min):
Address to Clock (A[3:0], B[3:0] to CK)
Write Enable (WREN) to Clock (A4/B4 to CK) MEM*_WRSET
Write-port Enable (WPE) to Clock (C0 to CK) MEM*_PWRSET 7.4
Data (WD[3:0] to CK)
MEM*_ASET
2.4
5.4
—
—
—
—
1.8
4.4
5.9
2.6
—
—
—
—
1.2
3.8
4.8
2.6
—
—
—
—
1.1
3.4
4.3
2.3
—
—
—
—
1.0
3.1
4.0
2.2
—
—
—
—
1.0
3.0
3.9
2.1
—
—
—
—
ns
ns
ns
ns
MEM*_DSET
3.5
0.0
—
Hold Time (TJ = All, VDD = All): All
Clock to PFU Out (CK to Q[3:0])—Register
TH
—
0.0
—
—
0.0
—
—
0.0
—
—
0.0
—
—
0.0
—
—
ns
ns
REG_DEL
2.4
2.0
1.9
1.5
1.3
1.0
Note: Speed grades of -5, -6, and -7 are for OR2TxxA devices only.
Table 38B. OR2TxxB Asynchronous Memory Read During Write, Clocking Data into Latch/Flip-Flop
(MA/MB Modes)
OR2TxxB Commercial: VDD = 3.0 V to 3.6 V, 0 °C ≤ TA ≤ 70 °C; OR2TxxB Industrial: VDD = 3.0 V to 3.6 V, –40 °C ≤ TA ≤
+85°C.
Speed
Parameter
Symbol
Unit
-7
-8
Min
Max
Min
Max
Setup Time (TJ = 85 °C, VDD = min):
Address to Clock (A[3:0], B[3:0] to CK)
Write Enable (WREN) to Clock (A4/B4 to CK)
Write-port Enable (WPE) to Clock (C0 to CK)
Data (WD[3:0] to CK)
MEM*_ASET
MEM*_WRSET
MEM*_PWRSET
MEM*_DSET
0.9
2.9
3.7
2.0
—
—
—
—
0.8
2.5
3.2
1.7
—
—
—
—
ns
ns
ns
ns
Hold Time (TJ = all, VDD = all): All
TH
0.0
—
—
0.0
—
—
ns
ns
Clock to PFU Out (CK to Q[3:0])—Register
REG_DEL
1.0
1.0
